SUNTEC - FUEL UNIT B2TA-8260B B20

The SUNTEC B2TA-8260B B20 is a two-stage fuel unit designed for use with biodiesel blends up to 20% (B20). Here are its key technical specifications:

• RPM: Operates at 3450 RPM
• Pressure: Factory-set at 100 PSI, with an adjustable range of 100-200 PSI
• Fuel Compatibility: Suitable for No. 2 fuel oil and biodiesel blends up to 20% (B20)
• Flow Rate: Delivers up to 23 GPH at 100 PSI
• Installation: Can be mounted in any position except upside down or with the shaft pointing upwards. Supports single-pipe installations up to 6" Hg vacuum and two-pipe installations up to 17" Hg vacuum
• Inlet/Return Pressure: Maximum of 10 PSI for lift or gravity feed applications
• Port Sizes: Inlet and return ports are 1/4-18 NPTF
• Special Features: Includes a strainer and nozzle port located on the right-hand side

This unit is versatile and reliable, making it suitable for various heating applications involving biodiesel and other compatible fuels.
