SUNTEC A2VA-3106B B20, FUEL UNIT

The SUNTEC A2VA-3106B B20 is a single-stage fuel unit designed for use with biodiesel blends up to 20% (B20). Here are its key technical specifications:

• RPM: Operates at 3450 RPM
• Pressure: Factory-set at 100 PSI, with an adjustable range of 100-200 PSI
• Fuel Compatibility: Suitable for No. 2 fuel oil and biodiesel blends up to 20% (B20)
• Installation: Can be mounted in any position. Supports single-pipe installations up to 6" Hg vacuum and two-pipe installations up to 12" Hg vacuum
• Inlet/Return Pressure: Maximum of 10 PSI for lift or gravity feed applications
• Port Sizes: Inlet port is 1/4-18 NPTF, and the nozzle port is 1/8-27 NPTF
• Flow Rate: Delivers 3 GPH at 100 PSI and 2 GPH at 200 PSI
• Special Features: Includes Viton O-rings and lip seals, and special materials for the piston and diaphragm valve to ensure compatibility with biodiesel

This unit is versatile and reliable, making it suitable for various heating applications involving biodiesel and other compatible fuels.
