SUNTEC A2RA-7720, WASTE OIL UNIT

The SUNTEC A2RA-7720 is a single-stage oil pump designed for waste oil applications. Here are its key technical specifications:

• RPM: Operates at 3450 RPM
• Pressure: Factory-set at 100 PSI, with an adjustable range of 100-150 PSI
• Fuel Compatibility: Suitable for kerosene, No. 1, and No. 2 fuel oil
• Installation: Can be mounted in any position. Supports single-pipe installations up to 6" Hg vacuum and two-pipe installations up to 12" Hg vacuum
• Inlet/Return Pressure: Maximum of 10 PSI for lift or gravity feed applications
• Port Sizes: Inlet port is 1/4-18 NPTF, and the nozzle port is 1/8-27 NPTF
• Flow Rate: Delivers 0.4 GPH at 100 PSI
• Special Features: Includes a relief port and is specifically designed for waste oil applications

This unit is versatile and reliable, making it suitable for various heating applications involving waste oil and other compatible fuels.
