SUNTEC A1RA-7738, WASTE OIL UNIT

The SUNTEC A1RA-7738 is a single-stage oil pump designed for waste oil applications. Here are its key technical specifications:

• RPM: Operates at 1725 RPM.
• Pressure: Factory-set at 100 PSI, with an adjustable range of 100-150 PSI.
• Fuel Compatibility: Suitable for kerosene, No. 1, No. 2 fuel oil, and waste oil. Not compatible with fuel blends containing more than 5% biodiesel
• Installation: Designed for single-pipe systems only. It has a high single-pipe lift capacity and requires an external strainer in the inlet line
• Port Sizes: Inlet port is 1/4-18 NPTF, and the nozzle port is 1/8-27 NPTF
• Flow Rate: Delivers 2.5 GPH at 100 PSI
• Strainer: Equipped with a 30x30 mesh strainer; an external 100x100 mesh strainer is recommended for the inlet line
• Suction Height: Maximum of 20" Hg for waste oil and No. 4 fuel, and 10" Hg for No. 2 and lighter fuels

This unit is reliable and efficient, making it suitable for various heating applications involving waste oil and other compatible fuels.
