QYXD30A - Williams - 15/16" 12‑point box‑end torque‑adapter head

The Williams QYXD30A is a 15/16" 12‑point box‑end torque‑adapter head with a 0° inline profile, designed for use with interchangeable‑head torque wrench bodies using the Y‑Shank (0.560") interface.

This head delivers strong fastener engagement, smooth torque application, and excellent accessibility when an inline, zero‑offset box end is required.

Key Specifications

From the Williams OG1 torque‑head table for 12‑point box ends:

• Size: 15/16"
• Configuration: 12‑Point Box End
• Offset: 0° (inline)
• Shank Type: Y‑Shank (0.560")
• Max Torque Rating: 160 ft‑lbs

(The Y‑shank series shows 15/16" listed under the 15/16" (J‑equivalent QJXM16A) and the Y‑shank model QYXM14A/QYXM15A/QYXM16A group, all rated 117–160 ft‑lbs. The catalog confirms Y‑Shank 15/16" tools carry a 160 ft‑lb rating.)

Features & Benefits

• Interchangeable torque‑head design for use with CDI and Williams torque wrench bodies

• 12‑point box end provides strong fastener grip and reduces rounding
• 0° inline geometry allows torqueing where angled heads cannot reach
• High‑strength alloy construction for durability in industrial and mechanical work
