Henry - Sight Glass Lens 1 FPT, clear, 25mm - LI48A-1

Henry LI48A-1 Sight Glass Lens 1 FPT, clear, 25mm.

Have a visual indication of liquid level. This may be achieved by use of a clear or “bullseye” glass.

Features

• Weld stub connection to tank shell
• Replaceable hermetically fused viewing lens
• Rated for high pressure
• Nickel plated steel body for moderate corrosion protection
• Two styles of glass for visual detection
• Can be fitted with optional frost shield

Product Details

• Part Number: LI48A-1
• Brand: Henry Technologies
• Series: Liquid Indicator Weld In Type
• Category: System Indicators › Sight Glasses
• Suitable For: Conventional Refrigerants
• Max Working Pressure: 69 Barg (1000 PSIg)
• Operating Temperature Range: -40˚C to +121˚C (-40°F to +250°F)
• Refrigerant Compatibility: A2L, CO2, HCFC, HFC and R717 where materially compatible
• Sizes Available: ø48.3 mm OD stub (ø1.9") 50.8 mm long stub (2") or 101.6 mm (4")
• Product Certification: CE and UL
