Henry 205-2-5/8, Check Valve, Brass Globe Type for Discharge Line, 2-5/8 ODS

Henry 205-2-5/8 Check Valve

Type: Brass Globe Type for Discharge Line

Connection Size: 2-5/8" ODS (Outside Diameter Sweat)

Description: The Henry 205-2-5/8 Check Valve is designed to allow fluid flow in one direction only, preventing backflow in discharge lines. This valve is particularly suitable for use in refrigeration and air conditioning systems, where it helps to maintain system efficiency and prevent damage to compressors and other components.

Key Features:

• Material: The valve body is constructed from robust brass, ensuring durability and resistance to corrosion.
• Design: Globe type design for efficient flow control.
• Spring: Made from stainless steel for reliable operation.
• Seat: PTFE (Polytetrafluoroethylene) seat for excellent sealing and chemical resistance.
• Flow Direction: Clearly marked with an arrow on the valve body.
• Operation: Quiet and efficient with minimal opening pressure.

Technical Specifications:

• Maximum Working Pressure: 500 PSI (34.5 Bar)
• Allowable Operating Temperature: -20°F to +300°F (-29°C to 149°C)
• Opening Pressure: Starts to open at 0.5 PSI and fully opens at 5 PSI pressure differential.

Applications:

• Ideal for installation downstream of an oil separator to prevent condensed liquid refrigerant from returning down the discharge line.
• Suitable for use with HCFC and HFC refrigerants and their associated oils, as well as other industrial fluids non-corrosive to brass, steel, copper, Teflon, and synthetic rubber.
