CA542 - Crown - IGNITER/ECLIPSE 14265-3 (18 In.) (EA)

⚡ CA542 Crown Igniter – Replaces Eclipse 14265-3 (18-Inch)

Extended-Length Ignition for Industrial Burners

The Crown CA542 Igniter is a direct replacement for Eclipse 14265-3, designed with an 18-inch tip and a 21.03-inch overall length for deep-set burner assemblies. Built for high-temperature performance and long service life, this igniter is ideal for industrial combustion systems requiring precise, reliable ignition.

✅ Key Features:

• 18-Inch Tip / 21.03-Inch Overall Length: Ideal for deep burner chambers and custom installations.
• Direct Replacement: Fully compatible with Eclipse 14265-3 and Auburn 3FR SPECIAL.
• High-Temperature Ceramic: Made from 95% pure alumina, rated up to 2700°F for extreme durability.
• Rigid Electrode: Constructed from Kanthal D alloy for strength and spark reliability.
• Threaded Mounting: 3/4"-14 NPT thread for secure installation in industrial burner systems.

📊 Technical Specs:

• Product Code: CA542
• Replaces: Eclipse 14265-3, Auburn 3FR SPECIAL
• Tip Length (B-Dimension): 18 inches
• Overall Length (A-Dimension): 21.03 inches
• Thread Size: 3/4"-14 NPT
• Material: 95% alumina ceramic, Kanthal D electrode
• Temperature Rating: Up to 2700°F
• Mounting: Threaded

🛠 Ideal For:

• Industrial gas and oil burners
• High-temperature combustion systems
• OEM and retrofit burner applications
• Maintenance and repair operations

💡 Pro Tip:

Always verify thread compatibility and insertion depth before installation. Use dielectric grease on terminals to prevent corrosion and ensure optimal conductivity in high-heat environments.
