CA530 - Crown - IGNITER/ECLIPSE 12392-1 I-34-26 (EA)

⚡ CA530 Crown Igniter – Replaces Eclipse 12392-1 & Auburn I-34-26

Extended-Length Ignition for Industrial Burners

The Crown CA530 Igniter is a direct replacement for Eclipse 12392-1 and Auburn I-34-26, designed for high-temperature industrial burner systems. With a 26-inch tip length and 29.44-inch overall length, this igniter is ideal for deep-set combustion chambers requiring long-reach ignition.

✅ Key Features:

• 26-Inch Tip / 29.44-Inch Overall Length: Provides extended reach for large industrial burner assemblies.
• Dual Compatibility: Replaces both Eclipse 12392-1 and Auburn I-34-26, simplifying inventory and service.
• High-Temperature Ceramic: Made from 95% pure alumina, rated up to 2700°F for extreme durability.
• Rigid Electrode: Constructed from Kanthal D alloy for consistent spark performance and long service life.
• Threaded Mounting: 3/4"-14 NPT thread for secure installation in industrial burner systems.

📊 Technical Specs:

• Product Code: CA530
• Replaces: Eclipse 12392-1, Auburn I-34-26
• Tip Length (B-Dimension): 26 inches
• Overall Length (A-Dimension): 29.44 inches
• Thread Size: 3/4"-14 NPT
• Material: 95% alumina ceramic, Kanthal D electrode
• Temperature Rating: Up to 2700°F
• Mounting: Threaded

🛠 Ideal For:

• Industrial gas and oil burners
• High-temperature combustion systems
• OEM and retrofit burner applications
• Maintenance and repair operations

💡 Pro Tip:

Always verify thread compatibility and insertion depth before installation. Use dielectric grease on terminals to prevent corrosion and ensure optimal conductivity in high-heat environments.
