CA233 - Crown - IGNITER/ECLIPSE 17396 (EA)

The Crown CA233 igniter is a high-performance industrial igniter designed to replace the Eclipse 17396 and Auburn I-25 (4.55") models. It is commonly used in Eclipse AH burners and other direct spark ignition systems.

🔧 Specifications

• Model: CA233
• Replaces: Eclipse 17396, Auburn I-25 (4.55")
• Mounting Thread: 1/2"-14 NPT
• A Dimension: 7.02"
• B Dimension (Insertion Length): 4.55"
• C Dimension: 0.12"
• Ceramic: 95% pure Alumina, rated up to 2700°F
• Electrode Material: Kanthal D, known for high strength and rigidity

✅ Compatibility

• Direct replacements:
  • Auburn I-25 (4.55")
  • Eclipse 17396
  • Crown CA233
  • Thermal P5019
