370G - Henry - 1/2 x 1/2 FPT - 12.7mm - Angle Handwheel

The Henry 370G is a packed angle shut-off valve with a handwheel design, commonly used in industrial ammonia refrigeration systems. Here's a detailed overview of its specifications:

🔧 Technical Specifications

• Model: 370G
• Valve Type: Packed Angle Shut-Off Valve
• Operation: Handwheel
• Connection Size: 1/2" FPT x 1/2" FPT (Female Pipe Thread)
• Material:
  • Valve Body: Ductile iron
  • Bonnet: Flanged ductile iron (accepts seal caps)
  • Stem: Stainless steel
• Backseating: Can be repacked under pressure
• Temperature Rating: -20°F to +325°F (-29°C to +163°C)
• Maximum Cold Working Pressure: 400 PSI (27.6 bar)
• Valve Open Height: 6.0 inches
• Weight: Approximately 2 lbs

🧰 Applications

• Designed for industrial ammonia systems
• Suitable for manual shut-off and isolation in high-pressure refrigeration circuits
