Oil Pump, Fuel Unit - - Suntec

The SUNTEC A2VA-3006B B100 is a fuel unit designed for use with various types of fuel oil. Here are some key technical details:

• Application: Suitable for fuel oil #2 and lighter, B6-B20 biodiesel blends.
• System: Can be used in one or two-pipe systems.
• Pressure Regulation: Incorporates a pressure regulating valve.
• Cut-off Function: High-speed cut-on and cut-off at full operating speed.
• Mounting: Flange mounting.
• Connection Threads:
  • Inlet and return: 1/4 NPTF
  • Nozzle outlet: 1/8 NPTF
  • Pressure gauge port: 1/8 NPTF
  • Bleeder valve port: 1/8 NPTF
• Operating Viscosity: 2 - 75 mm²/s (cSt).
• Oil Temperature: 50 - 115°F.
• Inlet Pressure: 10 psi max (NFPA limits to 3 psi max).
• Return Pressure: 10 psi max (NFPA limits to 3 psi max).
• Suction Height:
  • Single pipe: 6" Hg max vacuum.
  • Two-pipe: 12" Hg max vacuum.
• Rated Speed: 3450 rpm.
• Flow Rate:
  • 4 GPH at 100 psi.
  • 3 GPH at 200 psi.
• Solenoid Valve Voltage: 110-120V, 50/60 Hz.
• Power Consumption: 9W.
• Weight: Approximately 3 lbs.
