Filter, 3/8 Flare, Oil - Henry

The Henry S-4004 Oil Line Strainer & Filter is designed to remove contaminants from refrigerant oil, protecting compressors and other components in oil management systems. Here are the key technical details:

Main Features:

• High Flow Capacity with Low Pressure Drop: Ensures efficient operation without significant loss of pressure.
• Filter Area: 475 square inches, providing extensive filtration surface.
• Particle Retention: Capable of filtering particles down to 10 microns, effectively capturing debris such as dirt and metal chips.
• Connection Size: 3/8-inch flare fitting for easy integration into existing systems.

Applications:

• Suitable for both low and high-pressure oil management systems.
• Can be used with HFC and HCFC refrigerants and their associated oils, as well as other non-corrosive industrial fluids.

Technical Specifications:

• Maximum Working Pressure: 450 PSI (31 Bar).
• Operating Temperature Range: 14°F to 212°F (-10°C to +100°C).
• Materials: Carbon steel for pressure-bearing components, steel internal spring, and synthetic rubber O-ring.

Installation Notes:

• Must be installed according to the flow direction arrow.
• Recommended to replace the unit after a 15 PSI (1 Bar) pressure drop is detected.
• For low-pressure systems, it should be placed between the oil separator and oil reservoir.

This filter is a reliable choice for maintaining the cleanliness and efficiency of your oil management system.
