Henry Receiver, ASME, 323.9 x 1219.2mm, 1-5/8 ODS - S-8552

Original price $2,721.00 - Original price $2,721.00
Original price
$2,721.00
$2,721.00 - $2,721.00
Current price $2,721.00
SKU HEN-S-8552
Availability:
We will Check on Delivery Time and Advise

Henry S-8552 Receiver, ASME, 323.9 x 1219.2mm, 1-5/8 ODS.

Store liquid refrigerant to provide continuous flow of liquid refrigerant to the expansion device and provide storage for the refrigerant charge during system service or maintenance.

Features

  • Rugged coating for protection
  • Standard NPT PRV port
  • Can be fitted with a choice of isolating valves
  • Mounting legs on all models
  • Can be highly customized to suit application
  • Can be fitted with sight glasses, or ports to fit liquid level switches or probes

Product Details

  • Part Number: S-8552
  • Brand: Henry Technologies
  • Series: Vertical Liquid Refrigerant Receiver (ASME)
  • Category: Pressure Vessels › Liquid Refrigerant Receivers
  • Suitable For: Conventional Refrigerants
  • Max Working Pressure: 31 Barg (449.6 PSIg) up to 130 Bar (1885 PSIg). Consult with Factory
  • Operating Temperature Range: -29˚C to +121˚C (-20°F to +250°F)
  • Refrigerant Compatibility: A2L, CO2, HC, HCFC, HFC, HFO and R717 where materially compatible
  • Sizes Available: Inlet/Outlet Connections from 3/8" up to 2-1/8" with Rotalock valves or as ODS fittings Can be customized with various options Pump down capacities from 7.5 kg up to 225 kg (16 lbs to 500 lbs)
  • Product Certification: ASME
